Stud Mount 6A-600A 200VDC Industrial Power Fuses High Speed Type For Car

Ask Lasest Price
Brand Name :	Tian Rui
Model Number :	S88 Series
Certification :	ROHS
Price :	Negotiable
Payment Terms :	D/P, T/T,Paypal, Western Union
Supply Ability :	1000000PCS/Month
Delivery Time :	5-7 Days

Add to Cart

Product Details
Company Profile

Stud Mount 6A-600A 200VDC Industrial Power Fuses High Speed Type For Car

S88 Electric Vehicle Protection Stud Mount Bolted DC Cylindrical Porcelain Car High Speed Fuse Link

Specifications

S88 Style Stud-Mount Fuses 6A~600A 200Vdc

Class of Operation: EV fuse

Rating: •Amps: 6-600A •Volts: 200Vdc

Breaking Capacity: •Max:20kA@200Vdc •Min:200%In@200Vdc

Standards / Approvals

•Designed to:JASO-D622/ISO8820/GB31465

•Manufactured under a IATF16949 quality system for compliance with automotive requirements

•Reach declaration available upon request

•CE

•RoHS compliant

Features & Benefits

•Excellent DC performance

•Low arc voltage and low energy let-through(I2t)

•Superior cycling capability

•EV/HEV Application

Dimensions(Unit:mm)

Rated Current	Type	A士1.5	B士1.0	C士1.0	D士1.5	E士1.5	F士0.5	G士1.0	H士0.5	J士0.5	P士1.0
6-160A .	LET	55.5	17.7	25	38.5	44.5	6.5	12	2	9.5	16.2
180-300A	LMT	64.5	29	29	43	48.5	8.1	20	3	10.7	31.5
315-600A	LMT	88	37.5	30.5	55	65	11	25	3	16	39.5
160-600A	LMTS	84	38	30.5	50.5	61.5	10.5	25.5	3	16	42

Electrical Characteristics

Serial number	Part Number	Rated Current (A)	Energy Integrals I t Pre-Arcing Clearing at 200V		Watts Loss (W)	Use bolts	Installation torque
1	LET-200-6A	6	3	9	0.8	M6	6.0±1.0(N.m)
2	LET-200-10A	10	9	28	0.9	M6	6.0±1.0(N.m)
3	*LET-200-12A	12	13	44	1.0	M6	6.0±1.0(N.m)
4	LET-200-16A	16	26	88	1.3	M6	6.0±1.0(N.m)
5	LET-200-20A	20	46	161	1.6	M6	6.0±1.0(N.m)
6	LET-200-25A	25	72	259	1.7	M6	6.0±1.0(N.m)
7	LET-200-32A	32	122	450	2.6	M6	6.0±1.0(N.m)
8	LET-200-35A	35	166	632	2.7	M6	6.0±1.0(N.m)
9	LET-200-40A	40	233	910	2.9	M6	6.0±1.0(N.m)
10	LET-200-50A	50	415	1659	3.4	M6	6.0±1.0(N.m)
11	LET-200-63A	63	737	3023	4.1	M6	6.0±1.0(N.m)
12	LET-200-80A	80	1659	6967	4.4	M6	6.0±1.0(N.m)
13	LET-200-100A	100	2592	11146	5.8	M6	6.0±1.0(N.m)
14	LET-200-125A	125	4115	18106	7.7	M6	6.0±1.0(N.m)
15	LET-200-150A	150	6636	29860	9.4	M6	6.0±1.0(N.m)
16	LET-200-160A	160	7788	35823	11.5	M6	6.0±1.0(N.m)
17	LMT-200-180A	180	5243	16253	15.9	M8	12.0±1.0(N.m)
18	LMT-200-200A	200	6272	20070	16.2	M8	12.0±1.0(N.m)
19	*LMT-200-225A	225	8357	27577	16.8	M8	12.0±1.0(N.m)
20	LMT-200-250A	250	10368	35251	17.5	M8	12.0±1.0(N.m)
21	*LMT-200-275A	275	12800	44800	18.1	M8	12.0±1.0(N.m)
22	LMT-200-300A	300	16056	57803	19.6	M8	12.0±1.0(N.m)
23	LMT-200-315A	315	17522	64831	23.2	M10	24.0±3.0(N.m)
24	LMT-200-350A	350	22303	84750	24.6	M10	24.0±3.0(N.m)
25	LMT-200-400A	400	31150	121485	28.5	M10	24.0±3.0(N.m)
26	LMT-200-450A	450	39649	158597	33.5	M10	24.0±3.0(N.m)
27	LMT-200-500A	500	55378	227049	36.2	M10	24.0±3.0(N.m)
28	LMT-200-600A	600	86528	363418	45.7	M10	24.0±3.0(N.m)
29	*LMTS-200-160A	160	3596	11146	12.8	M10	24.0±3.0(N.m)
30	*LMTS-200-180A	180	4794	15341	14.0	M10	24.0±3.0(N.m)
31	*LMTS-200-200A	200	6272	20698	15.1	M10	24.0±3.0(N.m)
32	*LMTS-200-225A	225	8295	28202	16.7	M10	24.0±3.0(N.m)
33	LMTS-200-250A	250	10600	37099	18.1	M10	24.0±3.0(N.m)
34	*LMTS-200-275A	275	12800	46080	20.9	M10	24.0±3.0(N.m)
35	LMTS-200-300A	300	16056	59408	22.2	M10	24.0±3.0(N.m)
36	*LMTS-200-315A	315	17402	66129	23.6	M10	24.0±3.0(N.m)
37	LMTS-200-350A	350	22303	86981	24.6	M10	24.0±3.0(N.m)
38	LMTS-200-400A	400	30356	121426	30.2	M10	24.0±3.0(N.m)
39	LMTS-200-450A	450	39649	162562	33.5	M10	24.0±3.0(N.m)
40	LMTS-200-500A	500	55378	232587	33.2	M10	24.0±3.0(N.m)
41	LMTS-200-600A	600	83363	358459	37.4	M10	24.0±3.0(N.m)
