E87 E88 E89 Auto Manual Reset Maxi Blade Fuse Plug-in Resettable Type Car Circuit Breaker

Applications
Typically used in auxiliary and accessory circuits in truck, bus', RVs and marine systems . Others include battery chargers and DC audio systems. engine compartment and bilge area applications. Automatic reset, Modified reset and Manual reset is available.

Description
Based on the action characteristics of bimetallic sheet, it is used in AC and DC circuits where current overload or excessive protection is required.It is widely used in all kinds of machinery and electrical appliances, such as: automotive industry Denso products, winch, DC power supply appliances, electric vehicles, chargers, motors, etc

Specifications

• Single pole thermal type breakers.
• Rating:5-30A , 14 Vdc(E87&E88) ; 28Vdc(E89).
• Interrupt Rating: 150A -450A@ 14 Vdc.
• Operating Temperature Rating: -40 "C to 85 "C.
• Storage Temperature Rating: -40"C to 125 °C .
• Materials: UL-Rated 94VO thermoplastic body.Tin-plated copper alloy terminals.
• Marking: Standard marking includes amp/volt ratings. part number and date code.
• Termination: Compatible with ATC fuse blocks .
• Compliances: SAEJ553; SAEJ1171(ignition protected)

Standards
• Meet the requirements of SAE standard.
• In line with the EU ROHS environmental directive requirements.
• In line with the European Union REACH environmental directive requirements

Features
• High and low temperature resistance: insulation material design, use more safe and reliable, high and low temperature resistance.

• Metal material: metal material heat resistance is good, not easy to burn, high mechanical strength, not easy to damage, not easy to be
contaminated with dust and dirt

• Easy to use: small size, portable, do not occupy space, plug and play

• Reuse: good durability, not easy aging, can be reused

More About E8 Series Blade Car Resettable Circuit Breaker

With over-current protection and automatic recovery function

Useful item in any auto electrician's tool box

Ideal for race car APP

Electrical Characteristics

Note
