Car Blade 40A Automotive Fuse Middle Medium Standard Size ATU ATO ATC ATY low profile mini blade fuse

Ask Lasest Price
Brand Name :	Tian Rui
Model Number :	ATY
Certification :	ROHS UL
Price :	Negotiable
Payment Terms :	D/P, T/T,Paypal, Western Union
Supply Ability :	1000000PCS/Month
Delivery Time :	5-7 Days

Add to Cart

Product Details
Company Profile

Car Blade 40A Automotive Fuse Middle Medium Standard Size ATU ATO ATC ATY low profile mini blade fuse

Universal Middle Medium Standard Size ATU ATO ATC ATY Automotive Auto Car Blade Fuse

Specification of ATY Blade Fuse

Standard auto fuse current: 1A, 2A, 3A, 4A, 5A, 7.5A, 10A, 15A, 20A, 25A, 30A, 35A, 40A

Voltage: 32VDC

Material: zinc alloy, PC

Standards: According To SAE J1284

Certification: UL, ROHS

Description of ATC Fuse

The classic ATC fuse is a plastic blade type. The amperage is noted by both the color and printed on the top. You can test these fuses through the exposed tabs with a meter.

Features of ATO Fuse

Wide Applications - Vehicle fuses suitable for most vehicles using Blade Fuse:Marine, Boat, RV, ATV, UTV, Camper, Motorcycles, Snowmobiles, Truck etc.

Easy to Check - Transparent appearance makes it easy to confirm whether the fuse is blown.

Time -Current Characteristics of Automotive Standard Blade Fuse

% Of Ampere Rating	Opening Time
110%	>100 hours Min
135%	0.75 ~ 1800 s
200%	0.15~5 s
350%	0.04~0.5 s
600%	0.02~0.2 s

Details of Medium Car Blade Fuse

Part Number	Amperage	Rated Voltage	Voltage Drop	Body Color
ATY-1	1A	32V	250mV	0000
ATY-2	2A		225mV	0000
ATY-3	3A		200mV	0000
ATY-4	4A		200mV	0000
ATY-5	5A		175mV	0000
ATY-7.5	7.5A		150mV	0000
ATY-10	10A		140mV	0000
ATY-15	15A		125mV	0000
ATY-20	20A			0000
ATY-25	25A			0000
ATY-30	30A		120mV	0000
ATY-35	35A			0000
ATY-40	40A			0000

How to Use The Middle Blade Fuse

Step 1

Locate your car's fuse panel and the blown fuse. Fuse panels can usually be found under the steering wheel.Most cars have
one or two fuse boxes under the hood, next to the engine or battery. There may also be a fuse box inside the car, so keep looking
if the fuse you're looking for isn't here, or if all the fuses here are fine.Newer cars often have a fuse box underneath the dash
in an easily accessible location. Check the ceiling of the glove box for a hinge that swings downward. You may need a flat-head
screwdriver to open the lid.Older cars often have their fuses in an open box to the left of the brake pedal or the foot-operated
parking brake. It's difficult to examine the fuses closely in some models, so bring a flashlight and/or hand mirror.Less commonly,
the fuse box is located in the trunk or under the rear seat.

Step 2

Remove the broken fuse. You can use a variety of tools (or skip the tools and use your hands) to extract the blown fuse carefully. Before you open or work on a fuse box, be sure that your vehicle's ignition is turned off. Carefully remove fuses; they can break easily and a broken fuse is a lot harder to get out than a fully intact one.

Step 3

Insert a replacement fuse of the correct amperage—make note of the fuse panel and your owner's manual on this one.This one
MAY NOT FIT your car!Please check the fuse size before ordering, especially if you have a newer car and/or a foreign made car.

Step 4

Start the ignition to check if your handiwork has paid off. If the same fuse blows soon after you replaced it or doesn't work at all, it might be time for a trip to the mechanic.
