Series In-line Bayonet Knob In-Line Fuse Holder
Description of R3-32 In-line Fuse Holder
Fuse holders can be used in any applications where you need to
ensure electrical protection, isolation and switching under load of
inductive or resistive loads. The technology solutions applied to
reduce power dissipation help to minimize module heating.
Fuse holders are suitable for protection against overloads and
short circuits.
1. The price include one fuse holder, two red wires with terminal ,
one spring .
2. Housing: Bakelite
3. Color: Black
4. Wire length, color and diameter can be customized upon request.
and the price & the shipping fee maybe changed. Please contact us
for details.
| Product Name | R3-32 In-line Fuse Holder |
| Rated Current | 15A 20A |
| Rated Voltage | 32V 250V |
| Fuse Size | 5.2X20MM 6.35X30MM 6.35x31.8MM |
| Material | Bakelite |
| Terminal | Brass Tin Plated |
| Wire Gauge | 12AWG |
| Wire Length | Customized |
Dimension of 12AWG 15A 20A In-line Fuse Holder
Features of Heat-resistance Bakelite In-line Fuse Holder
To be safer, we use high-quality and safe materials to make the
plastic parts of the shell with strong electric current. After
professional flame-retardant testing, we effectively regulate the
hidden danger of fire.
Application of 5.2X20MM 6.35X30MM 6.35x31.8MM In-line Fuse Holder
In-line fuse holders are mostly used in car charging piles and
industrial mechanical circuits.
Contact Details:
Andy Wu
Email: andy@tianrui-fuse.com.cn
Tel/Whatsapp: +86 13532772961
Wechat: HFeng0805
Skype: andywutechrich
QQ: 969828363
More about Fuse Holders
Fuse holders refer to holders used to install fuses. Fuse holders
can be divided into: panel-mounted fuse holders, PCB-mounted fuse
holders, lead-type fuse holders and car fuse holders. Panel-mounted
fuse holders (mostly used in electrical equipment, such as power
amplifiers) , DVD, sound box, massage chair and other electrical
equipment); Leaded fuse holder (mostly used for the connection of
small household appliances and industrial machinery wiring
harness); PCB fuse holder (mostly used on the control board of
small household appliances) and fuse clips (mostly used for small
household appliances) Control panel). Car fuse holders can be
divided into leaded car fuse holders (multi-purpose car and
industrial machinery wiring harness); panel-mounted car fuse
holders (mostly used in car electrical appliances, such as car
amplifiers, car refrigerators, car DVDs, etc.) and car fuse clips.
Fuse holders have requirements for current resistance, voltage
resistance, and fire rating, and generally need to pass UL CSA VDE
ROHS and other safety regulations and EU certification.
Improved Structure of Fuse Holder
The improved structure of the fuse holder, in particular, refers to
a fuse holder that can display the status of the fuse and does not
need to replace its resettable fuse. It includes:-a first
conducting body with a plurality of screw holes and a socket
respectively communicating with each other, each screw hole is
screwed into abutting screw; a plurality of second conductors each
having a screw hole and a socket communicating with each other The
whole body, each screw hole is screwed into-abutting screw; several
are electrically connected to the resettable fuse between the first
conductive body and each second conductive body;-the top side is
fixed The base of the first and second conductive bodies;-an upper
cover covering the base; and a circuit board fixed on the upper
cover and provided with a plurality of light-emitting components,
which is connected to the first conductive body and Each second
conductive body forms an electrical connection.
