12V 24V Marine Boat Overload Protector Automatic Reset Waterproof Battery Circuit Breaker with Red Cover

Overcurrent circuit breaker with bi-metal structures, when the circuit is overload, can achieve rapid power off protection function.

E5 Series Waterproof Overload Protector Circuit Breaker with Red Cover

Specifications of Waterproof Overload Protector Circuit Breaker with Red Cover

Single Pole Thermal Type Breakers

Applications: Typically used in Battery chargers, trucks, buses, RV’s, trolling motors, etc.

Rating: 5-50A, 14VDC; 28VDC (Series E51, E53).

Interrupt Rating: Main Circuit Protection: 1.5kA @ 12VDC (Series E51 E53 );

Branch Circuit Protection: 2.5kA @ 12VDC (Series E51 sealed & Series E53 plastic cover).

Operating Temperature Rating: –40°F (–40°C) to 185°F (85°C)

Storage Temperature Rating: –40°F (–40°C) to 260°F (125°C)

Materials: Black UL-Rated thermoplastic body (thermoset for Type II body & buttons). Cover is grey
thermoplastic or steel-Type l gold, Type ll silver

Marking: Standard marking includes amp ratings and part numbers. Custom markings also available.

Termination: #10-32 thread and quick-connect options available

Torque Rating: 24 in-lbs (2 7N•m) max

Mounting Torque Rating: Plastic cover in-lbs (1 7N•m) . Metal cover 30 in-lbs (3 4N•m).

Ingress Protection Rating: IP66 On plastic cover version only (except for terminals)

Compliances: SAE J553; SAE J1171 ((consult factory for Ignition Protection ratings))

Dimension of Waterproof Overload Protector Circuit Breaker with Red Cover

Wiring of Waterproof Overload Protector Circuit Breaker with Red Cover

Six way wiring diagram:
360° wiring design, easy and quicker to install

Temperature Degrating Curves of Waterproof Overload Protector Circuit Breaker with Red Cover

Application of Waterproof Overload Protector Circuit Breaker with Red Cover

Transportation equipment, marine, medical, and other power

supplies:
1.Circuit breaker can do is protect the circuit from a high current short circuit.
2.Through its thermal trip it can protect the circuit from overload conditions. A circuit breaker will trip if too large a draw or current flow occurs across a thermal shunt inside.
3.Easy for mounting.
4.Trip-off time is customizing and adjustable according to customers' demands.
5.The design allows the thermal circuit breaker to be extremely cost-effective while remaining durable and reliable.
