Littelfuse MEGA Bolt Down Fuse 0298500.ZXH 0298 298 Series 500A 32V

Ask Lasest Price
Brand Name :	Tian Rui
Model Number :	MEGA
Certification :	ROHS
Price :	Negotiable
Payment Terms :	D/P, T/T,Paypal, Western Union
Supply Ability :	1000000PCS/Month
Delivery Time :	5-7 Days

Add to Cart

Product Details
Company Profile

Littelfuse MEGA Bolt Down Fuse 0298500.ZXH 0298 298 Series 500A 32V

Black Bakelite Bolt Down Type Car ANM Automotive Auto High Current 200A 400A 500A 300 AMP Fuse

Specifications

1. Rated Current: 40A to 500A;

2. Interrupting Rating: 2000A@32VDC;

3. Voltage Rating: 32VDC;

4. Operating Temperature Range: -40C ~ 125C;

5. Terminals: Copper/Zn alloy.

6. Housing Material: PA66/PPA(33% or 35%GF);

7. Mounting torque: 12- 18Nm W/M8;

Functional Characteristics

TESTING CURRENT	BLOW TIME LIMIT
100%	4 Hr. minimum
135%	1 20seconds--- 1800seconds
200%	1seconds --- 15 seconds
350%	0.3sec-5sec
600%	0.1seC- 1sec

Fuse List

ITEM	ITEM	RATING	ASSEMBLY P/N
1	32V	40A *	ANM-40A
2	32V	60A *	ANM-60A
3	32V	80A	ANM-80A
4	32V	100A	ANM-100A
5	32V	125A	ANM-125A
6	32V	150A	ANM-150A
7	32V	175A	ANM-175A
8	32V	200A	ANM-200A
9	32V	250A	ANM-250A
10	32V	300A **	ANM-300A
11	32V	350A **	ANM-350A
12	32V	400A **	ANM-400A
13	32V	450A **	ANM-450A
14	32V	500A **	ANM-500A

8. Standard: IS08820-5/UL248 special purpose fuses;

9. "*" not mentioned in ISO standards;

10. "**" is only for short circuit protector.

Description

ANM Bakelite Fuse is designed for high current circuit protection up to 500A. ANM Fuse also provides time delay characteristics. This fuse is ideal for battery and alternator protection application and other heavy gauge cables requiring ultra-high current protection.

Features

* Reliable Circuit Protection

* High Conductivity Plating

* Maximum Current Transfer

* 40-500 Amp - 5pcs/Pack

* MEGA style fuses

Drawing(Unit:mm)
